Vue Workstations

Start your Project Jump to specs

Everything in full Vue

Introducing the new Vue Workstation. As the name suggests, you’re going to see desks in a brand-new light. Configurable. Connectable. Adjustable. Just plain more than able. And even able to accommodate multi-operator solutions. Available in static or height adjustable. Horizontal/Vertical adjustable monitor mounts offer complete ergonomic viewing. Or should we say Vue-ing? Because everything allowing a mission critical room to operate with 100% focus went into every design detail. Like your choice of an open architectural design or a closed design with lower section doors. Color options. Worksurface options. The only option you don’t have is to sit at a desk not clearing a path for you to do your job at your very best. You’re going to love the Vue. From here, you can see all the way to success.

Configurable. Connectable. Adjustable. Just plain more than able.

Everything allowing a mission critical room to operate with 100% focus went into every design detail.

Modern Design

Open and closed base versions. Unmatched design possibilities. It’s forward-thinking with everything thought through and thought out.

Ergonomic Monitor Mounts with Versa-Trak

Infinite monitor arm adjustability. This is versatility completely on the right track.

Console Sizes

Vue is available in several sizes and configurations:

  • 59", 75", 83", 90" and 99"
  • Sit-stand and stationary
  • Open- and closed-base
  • Linear and curved
Additional Features

Operator Convenience

Impeccably designed cable management means more space, more control and less clutter allowing for the easiest access. Easiest everything.

Space & Power

Space & Power

Work Surface Options

Laminate With Safeguard

Choose from a broad range of colors, textures and patterns. We supply laminates from all the major manufacturers. The high-pressure laminate is bonded to a 1-1/8″ thick MDF core for strength and the work surface is finished with our durable Safeguard Edge.

FEATURES

  • Durable high-pressure plastic laminate surface
  • Available in a wide variety of colors and patterns
  • Optional textures and gloss levels available
  • Laminate is bonded to 1-1 /8″ thick MDF core
  • Easy to clean and maintain
  • Safeguard Edge provides exceptional durability

Comfort Edge

Our urethane Comfort Edge work surface offers the ultimate in flexibility and durability. The black urethane edge is molded to 1-1/8″ laminated industrial-grade 45lb. particleboard. We can supply laminates from any of the major manufacturers. The Comfort Edge work surface features a smooth, contoured profile to improve operator comfort and maximize productivity.

  • Permanently bonded black urethane creates a long-lasting, water-tight seam with a smooth finish
  • Ergonomic profile provides comfort and reduces the risk of injury from sharp edges
  • Antibacterial and antifungal additives promote a healthy work environment
  • UV-resistant urethane will not change color or deteriorate over time
  • Suitable for the most demanding 24/7 control room operations

Solid Surface

Corian work surfaces are durable and feature an attractive, seamless appearance. The solid colors penetrate through the entire thickness of the material so blemishes are easily repaired. The smooth, nonporous finish is hygienic and easy to clean while being resistant to liquids and heat.

  • Easy to clean and stain-resistant because liquid cannot penetrate the surface
  • Durability and renewability with common abrasive cleaners reduce the need for replacement, which makes Corian inherently environmentally friendly
  • Joints are unobtrusive and impermeable with a seamless appearance
  • Colors and patterns penetrate through the surface and cannot wear away
  • Inert, non-toxic, chemically unreactive, hypoallergenic and fire-resistant
  • Advanced blend of natural minerals and acrylic polymer
SPECIFICATIONS
SYSTEM COMPONENTS
  • Pre-engineered modular construction.
  • Available from pre-defined set of manufacturer’s model numbers.
  • Free from alterations to design either prior to or following installation.
  • Supplied knocked-down; assembly accomplished without need for welding
or modifications.
  • Constructed of steel superstructure framework consisting of end frames connected by horizontal crossbar.
ELECTRIC LIFT LEGS
  • Incorporated fully integrated aluminum track system capable of supporting variety of monitor arrays.
  • Provide uninterrupted lateral adjustability
of monitors.
END FRAMES
  • Capable of integrating one set of electric-lift columns along with cable followers in horizontal crossbar.
  • Support fully loaded console and incorporate threaded adjustable glides.
  • Incorporate lift off panel on the open base console legs.
  • Height-Adjustable Consoles: Comprised of steel end frames with two electric-lift legs and ergonomic work surfaces.
CABLES MANAGEMENT
  • 1.5 x 3 inches; two per work surface on height-adjustable consoles.
  •  Integrated cable channel in base.
VERSA-TRAK/MONITOR ARRAYS
  • Incorporated fully integrated aluminum track system capable of supporting variety of monitor arrays.
  • Provide uninterrupted lateral adjustability
of monitors.
WARRANTIES
Downloads

Spec Sheets and brochures

Standard Details

Vue-L 59" console (Linear work surface)

Vue-L 83" console (Linear work surface)

Vue-C 75" console (Curved work surface)

Vue-C 90" console (Curved work surface)

Vue-C 99" console (Curved work surface)
